In Wall Toilet Suite New Ceramic P-Trap Soft Close Seat Concealed Cistern Curve [Push Panel Design: Black Square]
RRP $599.00
$593.00
SAVE $6.00 (1%)
In Stock
! Attention shoppers ! Don't compromise on quality.
Many substandard suites are available on the market. Identical designs are produced by various manufacturers resulting in vast quality differences.
Our suites have a high quality finish and rich white porcelain glaze, we invite you to inspect and compare - you will see the difference. Happy shopping!
Many substandard suites are available on the market. Identical designs are produced by various manufacturers resulting in vast quality differences.
Our suites have a high quality finish and rich white porcelain glaze, we invite you to inspect and compare - you will see the difference. Happy shopping!
Modern Cube Design Windsor In-Wall Cistern & Floor Mount Pan
Concealed cistern for minimalistic elegance, latest European design pan with chrome push button flush.
Features
- Back to Wall Floor Mount Pan & Concealed In Wall Cistern(plumbing connections completely concealed within the pan)
- Manufactured to Australian Standards
- Heavy Duty Quick Release Soft Close Seat and Lid, featuring push button removal for easy cleaning
- Full back to wall pan with completely concealed cistern
- Push Panel Options: Chrome Round, Chrome Square, Black Square
- Flush mechanist accessible & removable via push button wall plate for cleaning and maintenance (if required)
- Suitable for both Floor waste (S Trap) and Wall waste (P Trap) waste outlets (accessories and instructions provided)
- Multiple Water Inlet Options: left, right and rear
- Solid Full Ceramic Construction
- Easy to install (recommended for installation by a licensed plumber or as required by local state or territory)
Specification
- Watermark approved
- WELS Star water Rating
- Dual Flush Mechanism 4.5 / 3.0L providing economical water consumption
- S Trap (wall to waste centre) adjustable between 50 - 100 mm (150-180mm with optional adaptor +$5)
- P Trap (floor to waste centre) 180mm
- Warranty for manufacturers faults or defects:
5 Year warranty on vitreous China
2 Year warranty on valves and fixing kit
- Dimensions: Width 355 x Length 590mm x Height 405 mm (See Diagram for detailed specificatons)
- Manufactured to Australian Standards
- Heavy Duty Quick Release Soft Close Seat and Lid, featuring push button removal for easy cleaning
- Full back to wall pan with completely concealed cistern
- Push Panel Options: Chrome Round, Chrome Square, Black Square
- Flush mechanist accessible & removable via push button wall plate for cleaning and maintenance (if required)
- Suitable for both Floor waste (S Trap) and Wall waste (P Trap) waste outlets (accessories and instructions provided)
- Multiple Water Inlet Options: left, right and rear
- Solid Full Ceramic Construction
- Easy to install (recommended for installation by a licensed plumber or as required by local state or territory)
Specification
- Watermark approved
- WELS Star water Rating
- Dual Flush Mechanism 4.5 / 3.0L providing economical water consumption
- S Trap (wall to waste centre) adjustable between 50 - 100 mm (150-180mm with optional adaptor +$5)
- P Trap (floor to waste centre) 180mm
- Warranty for manufacturers faults or defects:
5 Year warranty on vitreous China
2 Year warranty on valves and fixing kit
- Dimensions: Width 355 x Length 590mm x Height 405 mm (See Diagram for detailed specificatons)
Package Contents
Toilet Cistern
Push Panel: Round, Square, Black (Options- specify with order)
Toilet Pan
Soft close seat and lid
P Trap (waste into wall) standard setup, S Trap Kit (waste into floor) included FREE (please request)
Fittings, accessories, instructions
Cistern Wels Spec G3003:
- Watermark Certified (Standards AS 1172.1 & AS 1172.2)
- WELS Registration Number: L05964
- 3 star WELS Rating
- 4.5 Litre Full Flush/ 3L Half Flush Dual Flush
Pan:
(TFK201-XXX)
| SKU | TFK201-XXX |
| Model # | K102-XXX |
| Barcode # | Does not apply |
| Brand | KDK |
| Shipping Weight | 120.0000kg |
| Shipping Width | 0.510m |
| Shipping Height | 0.540m |
| Shipping Length | 0.600m |
| Shipping Cubic | 0.165200000m3 |
| Unit Of Measure | 1 |
